6) Loading Document Rolls
The IER 512C Printer may be fitted with an optional document roll
dispenser.
a) Take the removable flange (1) off the spindle (2).
b) Position the new roll of blank documents (3) so that the first label
is inserted heat-sensitive face uppermost.
c) Slide the core of the new roll (3) onto the hubs (4).
d) Lift the printhead lever (6) upwards.
e) Slide the document strip (5) into the paper guides making up the
front insertion slot until the strip emerges from the front
ejection slot.
f) Replace the removable flange (1) against the roll (3).
g) Lower the printhead lever (6). The document strip is
automatically ejected, possibly after some backward and forward
movements (separation mark self-calibration phase).
IMPORTANT
If positioning documents in the front insertion
slot poses a problem, check the paper path
adjustment (see Page 10).
The document roll must remain aligned with
the paper path. If the document roll is feeding
unevenly, reset the roll position (see Printer
Operation and Adjustment Manual).
