IET Labs DE-5000 User Manual

- 40 -
Inductance:
Range Resolution 100/120Hz 1kHz 10kHz 100kHz
20.000 µH 0.001 µH ─ ─ ─ 2.5%+5
200.00 µH 0.01 µH ─ ─ 1.2%+5 0.6%+3
2000.0 µH 0.1 µH ─ 2.0%+5 0.6%+3 0.6%+3
20.000 mH 0.001 mH 1.2%+5 1.0%+5 0.3%+2 0.6%+3
200.00 mH 0.01 mH 0.3%+2 0.6%+3 0.3%+2 1.2%+5
2000.0 mH 0.1 mH 0.3%+2 0.3%+2 0.6%+3 ─
20.000 H 0.001 H 0.3%+2 0.6%+3 1.2%+5 ─
200.0 H 0.1 H 0.6%+3 1.2%+5 ─ ─
2.000 kH 0.001 kH 1.2%+5 ─ ─ ─
*If reading <2000, unit on display is µH
DCR:
Range Resolution Accuracy
200.00 Ω 0.01 Ω 1.0%+3
2.0000 kΩ 0.0001 kΩ 0.2%+2
20.000 kΩ 0.001 kΩ 0.2%+2
200.00 kΩ 0.01 kΩ 0.5%+2
2.0000 MΩ 0.0001 MΩ 1.0%+3
20.000 MΩ 0.001 MΩ 2.0%+3
200.0 MΩ 0.1 MΩ 2.0%+3
Accuracy v.s. Resistance (Z
DUT
):
DCR 100/120Hz 1kHz 10kHz 100kHz
0.1-1 Ω 1.2%+5 1.2%+5 1.2%+5 1.2%+5 2.5%+5
1-10 Ω 0.6%+3 0.6%+3 0.6%+3 0.6%+3 1.2%+5
10-100 kΩ 0.3%+2 0.3%+2 0.3%+2 0.3%+2 0.6%+3
100 k-1 MΩ 0.6%+3 0.6%+3 0.6%+3 0.6%+3 2.5%+5
1 M-20 MΩ 1.2%+5 1.2%+5 1.2%+5 2.5%+5
2.5%+5
(2 MΩ max.)
>20 MΩ 2.5%+5 2.5%+5 2.5%+5 ─ ─
