- 39 -
3.2.
Accuracy specifications
Accuracy is specified at 23°C ± 5°C, <75% RH.
All accuracy is specified as ±[(% of reading) + (value of least
significant digit)].
For most precise measurements, the meter has to be zeroed first.
Resistance:
Range Resolution 100/120Hz 1kHz 10kHz 100kHz
20.000 Ω 0.001 Ω ─ 1.0%+3 1.0%+3 2.0%+3
200.00 Ω 0.01 Ω 1.0%+3 0.3%+2 0.3%+2 0.6%+3
2.0000 kΩ 0.0001 kΩ 0.3%+2 0.3%+2 0.3%+2 0.6%+3
20.000 kΩ 0.001 kΩ 0.3%+2 0.3%+2 0.3%+2 0.6%+3
200.00 kΩ 0.01 kΩ 0.5%+2 0.5%+2 0.5%+2 1.0%+3
2.0000 MΩ 0.0001 MΩ 1.0%+3 1.0%+3 1.0%+3 ─
2.000MΩ 0.001 MΩ ─ ─ ─ 2.0%+3
20.000 MΩ 0.001 MΩ 2.0%+3 2.0%+3 ─ ─
20.00 MΩ 0.01 MΩ ─ ─ 2.0%+3 ─
200.0 MΩ 0.1 MΩ 2.0%+3 2.0%+3 ─ ─
Capacitance:
Range Resolution 100/120Hz 1kHz 10kHz 100kHz
200.00 pF 0.01 pF ─ ─ 1.2%+5 2.0%+5
2000.0 pF 0.1 pF ─ 2.0%+3 0.3%+2 0.6%+3
20.000 nF 0.001 nF 2.0%+3 0.3%+2 0.3%+2 0.6%+3
200.00 nF 0.01 nF 0.3%+2 0.3%+2 0.3%+2 0.6%+3
2000.0 nF 0.1 nF 0.3%+2 0.3%+2 0.6%+2 2.0%+5
20.000 µF 0.001 µF 0.3%+2 0.6%+2 1.2%+5 ─
20.00 µF 0.01 µF ─ ─ ─
3.0%+5
(10µF max.)
200.00 µF 0.01 µF 0.6%+2 1.0%+3 ─ ─
200.0 µF 0.1 µF ─ ─
3.0%+5
(100µF max.)
─
2000.0 µF 0.1 µF 1.0%+3 ─ ─ ─
2000 µF 1 µF ─ 1.2%+3 ─ ─
20.00 mF 0.01 mF 1.2%+3 ─ ─ ─
*If reading <2000, unit on display is pF
