IET Labs DE-5000 - 2.4. Attaching DUTs to the Meter

- 17 -
2.4. Attaching DUT’s to the meter
Devices under test (DUT’s) may be connected to the
meter as follows:
•
Insert DIP component leads to the sockets directly.
•
Attach Alligator-clip test-lead adapter (TL-21)
Guard line (TL-
23) provides
a shield for DUT, preventing
interference when measuring
4-Wire Alligator
Test Lead Case
(TL-21)
