IFM Electronic DA102S - Error Message; Feedback Contact

11
UK
The device monitors continuously if this condition is met.
If this regulation is violated, there is an error and the device goes into the safe
state.
(→6.3Arrangementofthedampingcams)
5.9 Error message
If the device detects an error, the switching outputs are kept in the safe state.
The "Fault" LED is lit and the transistor output Y7 opens ("LOW" status).
Definition "safe state":
• Output relays K1/K2 are de-energised
• Switching outputs 13-14 and 23-24 open
• No standstill message
The error message is reset by interrupting the voltage supply.
5.10 Feedback contact
The device monitors the position of the guard locking by means of a feedback
contact.
• When a movement starts, the output relays K1/K2 are de-energised.
The switching outputs open.
The output LEDs K1/K2 flash when the feedback contact is open.
• If the input frequency is greater than the switch point and the feedback contact
is open, the output LEDs K1/K2 flash.
With resulting standstill and continually open feedback circuit the output relays
K1/K2 are not energised.
The switching outputs remain open.
There is no error message.
Transistor output Y7 remains closed ("HIGH" state).
(→7.5Feedbackcontact)
