IFM Electronic TW2000 - 8�3 Explanation Extended Functions; 8�4 Submenu Simulation (SIM)

17
UK
ASP2
Analogue start point with scaled measuring range for the analogue output
OUT2
AEP2
Analogue end point with scaled measuring range for the analogue output
OUT2
EF Opening the lower menu level "Extended functions"
8.3 Explanation extended functions (EF)
Parameters Function and setting options
rES Reset to factory settings
dS1
Switch-on delay for OUT1:
Value in seconds (maximum 10 s in steps of 0�1 s)
dr1
Switch-off delay for OUT1:
Value in seconds (maximum 10 s in steps of 0�1 s)
ou1
Output function for OUT1:
- Hno: Hysteresis normally open
- Hnc: hysteresis normally closed
uni Standard unit of measurement for temperature: °F or °C
dAP
Damping for the temperature display, switching output and analogue
output
PhLd Configuration of the peak-hold function
SIM Opening of the lower menu level "Simulation"
8.4 Submenu simulation (SIM)
Parameter Function and setting options
S�TMP Simulated temperature value
S�Tim Duration of the simulation in minutes
S�On
Start of the simulation:
- On (simulation starts)
- OFF (simulation inactive)
