CompactModul Metall CR2032
19
Index S-Idx Name Type Default Description
2000 4 Configuration
output
channel 4, pin 4
u8, rw 0x02 0 = OFF
2 = binary output
4 = analogue output (PWM)
2000 5 Configuration
output
channel 5, pin 4
u8, rw 0x0A 0 = OFF
A = binary input
B = binary input with diagnosis
2000 6 Configuration
output
channel 6, pin 4
u8, rw 0x02 0 = OFF
2 = binary output
4 = analogue output (PWM)
2000 7 Configuration
input
channel 7, pin 4
u8, rw 0x0A 0 = OFF
A = binary input
B = binary input with diagnosis
2000 8 Configuration
output
channel 8, pin 4
u8, rw 0x02 0 = OFF
2 = binary output
4 = analogue output (PWM)
2000 9 Configuration
input
channel 1, pin 2
u8, rw 0x03 0 = OFF
3 = voltage 0���10,000 mV
6 = ratiometric 0���1000 ‰
7 = current 0���20,000 µA
9 = voltage 0���32,000 mV
A = binary input
with analogue evaluation
B = binary input
with analogue evaluation (with
diagnosis)
2000 0A Configuration
output
channel 2, pin 2
u8, rw 0x02 0 = OFF
2 = binary output
2000 0B Configuration
input
channel 3, pin 2
u8, rw 0x03 0 = OFF
3 = voltage 0���10,000 mV
6 = ratiometric 0���1000 ‰
7 = current 0���20,000 µA
9 = voltage 0���32,000 mV
A = binary input
with analogue evaluation
B = binary input with analogue
evaluation (with diagnosis)
2000 0C Configuration
output
channel 4, pin 2
u8, rw 0x02 0 = OFF
2 = binary output
2000 0D Configuration
input
channel 5, pin 2
u8, rw 0x03 0 = OFF
3 = voltage 0���10,000 mV
6 = ratiometric 0���1000 ‰
7 = current 0���20,000 µA
9 = voltage 0���32,000 mV
A = binary input
with analogue evaluation
B = binary input
with analogue evaluation (with
diagnosis)
