CompactModul Metall CR2032
26
Index S-Idx Designation Type Default Description
1A01 2 Index in the
object directory
u32, ro 0x2002 02 Idx 2002, SIdx 02 contains the
analogue value channel 3, pin 2
voltage 0���10,000 mV
ratiometric 0���1000 ‰
current 0���20,000 µA
voltage 0���32,000 mV
binary input with analogue evaluation
01 00 00 00 00 00 00 00
binary input with analogue evaluation
(with diagnosis)
00 00 FE FF 00 00 00 00
= short circuit to V
BB
00 00 FF FF 00 00 00 00
= wire break/short circuit to ground
1A01 3 Index in the
object directory
u32, ro 0x2002 03 Idx 2002, SIdx 03 contains the
analogue value channel 5, pin 2
voltage 0���10,000 mV
ratiometric 0���1000 ‰
current 0���20,000 µA
voltage 0���32,000 mV
binary input with analogue evaluation
01 00 00 00 00 00 00 00
binary input with analogue evaluation
(with diagnosis)
00 00 00 00 FE FF 00 00
= short circuit to V
BB
00 00 00 00 FF FF 00 00
= wire break/short circuit to ground
1A01 4 Index in the
object directory
u32, ro 0x2002 04 Idx 2002, SIdx 04 contains the
analogue value channel 7, pin 2
voltage 0���10,000 mV
ratiometric 0���1000 ‰
current 0���20,000 µA
voltage 0���32,000 mV
binary input with analogue evaluation
01 00 00 00 00 00 00 00
binary input with analogue evaluation
(with diagnosis)
00 00 00 00 00 00 FE FF
= short circuit to V
BB
00 00 00 00 00 00 FF FF
= wire break/short circuit to ground
Explanation of the abbreviations:
0x��� = hexadecimal value
0b��� = bit coded
0d��� = decimal value
str = string
rw = read-write
ro = read only
u8 = unsigned 8 bit
u16 = unsigned 16 bit
