CabinetModule CR2016
27
Index S-Idx Name Typ Default Beschreibung
3 configuration binary
input 3
rw u8 0x0A 0x00 = off
0x0A = binary input
0x0B = binary input with diagnosis
0x0E = frequency input
4 configuration binary
input 4
rw u8 0x0A 0x00 = off
0x0A = binary input
0x0B = binary input with diagnosis
0x0E = frequency input
5 configuration binary
input 5
rw u8 0x0A 0x00 = off
0x0A = binary input
0x0B = binary input with diagnosis
6 configuration binary
input 6
rw u8 0x0A 0x00 = off
0x0A = binary input
0x0B = binary input with diagnosis
7 configuration binary
input 7
rw u8 0x0A 0x00 = off
0x0A = binary input
0x0B = binary input with diagnosis
8 configuration binary
input 8
rw u8 0x0A 0x00 = off
0x0A = binary input
0x0B = binary input with diagnosis
9 configuration binary
input 9
rw u8 0x0A 0x00 = off
0x0A = binary input
0x0B = binary input with diagnosis
0x0C = binary input with negative switching
A configuration binary
input 10
rw u8 0x0A 0x00 = off
0x0A = binary input
0x0B = binary input with diagnosis
0x0C = binary input with negative switching
B configuration binary
input 11
rw u8 0x0A 0x00 = off
0x0A = binary input
0x0B = binary input with diagnosis
0x0C = binary input with negative switching
C configuration binary
input 12
rw u8 0x0A "x00 = off
0x0A = binary input
0x0B = binary input with diagnosis
0x0C = binary input with negative switching
D configuration
analogue input 1
rw u8 0x03 0x00 = off
0x03 = voltage 0���10,000 mV
0x06 = ratiometric 0���1000 per mille
0x07 = current 0���20,000 µA
0x09 = voltage 0���30,000 mV
0x0A = binary input
0x0B = binary input with diagnosis
E configuration
analogue input 2
rw u8 0x03 0x00 = off
0x03 = voltage 0���10,000 mV
0x06 = ratiometric 0���1000 per mille
0x07 = current 0���20,000 µA
0x09 = voltage 0���30,000 mV
0x0A = binary input
0x0B = binary input with diagnosis
