IFM CR2016 - Analogue Output Configuration

CabinetModule CR2016
32
Index S-Idx Name Typ Default Beschreibung
5 analogue output 5 wo u8 0x00 0��10 per 10%
6 analogue output 6 wo u8 0x00 0��10 per 10%
7 analogue output 7 wo u8 0x00 0��10 per 10%
8 analogue output 8 wo u8 0x00 0��10 per 10%
9 analogue output 9 wo u8 0x00 0��10 per 10%
A analogue output 10 wo u8 0x00 0��10 per 10%
B analogue output 11 wo u8 0x00 0��10 per 10%
C analogue output 12 wo u8 0x00 0��10 per 10%
D analogue output 13 wo u8 0x00 0��10 per 10%
E analogue output 14 wo u8 0x00 0��10 per 10%
F analogue output 15 wo u8 0x00 0��10 per 10%
10 analogue output 16 wo u8 0x00 0��10 per 10%
The entries 20F0/20F1 and 20F2/20F3 must always contain identical values� The new entries are valid after a
reset (switching the module off/on)� Values outside the permissible ranges will be rejected�
Observe rotary switch position!
Entries under 20F0/20F1 and 20F2/20F3 are only valid if the rotary switches for baud rate and/or node ID are
in the position ”F”�
