ifm Device Manual SmartSPS AC14 with EtherNet/IP interface (AC1421, AC1422), Firmware 3.1.2 2015-11-30
Appendix AS-i master
>
DAE/EE flags
16935
The DAE/EE flags indicate if the double address detection and the earth fault detection are on.
The DEA/EE flags are saved in the following register:
DAE/EE flags
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
--
--
--
--
--
--
--
DAE
active
--
--
--
--
--
--
--
EE
active
Legend:
Flag
Designation
Description
Initial value at PowerOn
DAE
active
Double address
detection active
1 (TRUE):
0 (FALSE):
Double address detection is on.
Double address detection is off.
0 (FALSE)
EE active
Earth fault detection is
active
1 (TRUE):
0 (FALSE):
Earth fault detection is on.
Earth fault detection is off.
1 (TRUE)
