ifm Device Manual SmartSPS AC14 with EtherNet/IP interface (AC1421, AC1422), Firmware 3.1.2 2015-11-30
Menu System
>
Set the device cycle
11780
NOTICE
Risk of material damage to the machine/plant!
A device cycle that is too short can have undesirable effects on the correct transmission of the
process and control data between the PLC and peripheral devices (higher-level PLC, AS-i slaves).
► Ensure a sufficiently long cycle time!
If the PLC is disabled, the device operates with a fixed cycle time of 0.7 ms.
If the PLC is enabled, the operator can set the device cycle to a value between 1.5 ms and
3.0 ms. (→ Enable/Disable the device-internal PLC (→ page 76))
To set the device cycle:
1 Select the menu page
► >
► Select [System settings] tab.
2 Set the device cycle
► Set the following parameters as required:
Parameter
Meaning
Possible values
[Device cycle]
Active → Device parameters.
1.5 ms =
1.5 milliseconds
2.0 ms =
2.0 milliseconds
2.5 ms =
2.5 milliseconds
3.0 ms =
3.0 milliseconds
3 Save the changes
► Press [Accept selection].
> Selected value is applied.
