ifm Device Manual SmartSPS AC14 with EtherNet/IP interface (AC1421, AC1422), Firmware 3.1.2 2015-11-30
Menu System
>
5.4.4 System: Diagnosis
9053:
The [Diagnosis] menu item provides access to the diagnostic data of the device.
>
Display diagnostic data
15827
To display the diagnostic data of the device:
1 Select the menu page
► >
2 Display the diagnostic data
> Page shows the following information:
Designation
Meaning
Possible values
Operating time
[YY-DDD HH:MM]
Operating time of system and
components
All times indicated in [YY-DDD-HH:MM] format:
YY = years
DDD = days
HH = hours
MM = minutes
 total
Operating time of device
 current
Operating time of device since last
system start
 LCD
Operating time of LCD
 PLC
Operating time of controller
Temperature
Current device temperature
Indications in [°C] (→ Note)
Power supply
Voltage supply of device
Aux =
Voltage is supplied separately
by AS-i network and AUX 24
V.
AS-i =
Voltage is only supplied by the
AS-i network.
Power module =
Voltage is supplied by data
decoupling module.
The temperature monitoring of AC142n continuously checks whether the system
temperature exceeds the maximum permissible values. If certain limit values are
exceeded, the temperature monitoring generates warnings or error messages which
are displayed in the → Online Support Center (OSC) (→ page 123).
The following temperature ranges apply:
 Normal zone (0 °C ... 80 °C): no warnings, no error messages
 Transitional zone (80.1 °C ... 85 °C): warnings
 Critical zone: (> 85.1 °C): error messages
