22
8.8.3 Fault during the teach operation
The teach operation is cancelled in case of a fault:
> LEDs are flashing green/yellow with 8 Hz�
> The unit returns to the operating mode with unchanged settings�
Possible faults:
Time error (teach time too long / too short)
Internal sensor signal not clear
Wrong output function: (→ 8.8 Parameter setting via the teach input)
Process value too low (< 9 %, e�g� for powders), SPx/rPx must be set manually
(→ 8.1 Parameter setting via PC and IO-Link interface)
9 Operation
When the supply voltage has been applied, the unit is in the operating mode�
It carries out its evaluation functions and switches the outputs�
Outputs OUT1 and OUT2 complement each other
The following table shows the factory settings� In this state OUT1 = Hno
and OUT2 = Hnc�
Check whether the unit operates correctly
9.1 Switching states and display by LEDs
Operating status LEDs OUT1 OUT2
Unit ready for operation,
no medium detected
green OFF ON
Unit ready for operation, medium detected yellow ON OFF
No operating voltage OFF OFF OFF
Short circuit output 1 flashing yellow - 1)
Short circuit output 2 flashing yellow 1) -
Error / failure - OFF OFF
Teach operation (→ 8.8.1) and (→ 8.8.2)
Fault during the teach operation LEDs are flashing green/yellow with 8 Hz
1
) according to the level
The LEDs always indicate the switching status of output OUT1
(exception: Teach mode (→ 8.8))�
