Igloo Gastroline 1.5 - Fig.1 Construction of the Device; Fig.2 Stationary and Running System; Fig.3 Layout of GN Container

en
11
User manual Gastrolinewww.igloo.pl
Fig.1 construction of the device
1 – Glass shelf
2 – Aluminium lamp with backlight
3 – Front shelf for the client
4 – Front of the display cabinet
5 – Device levelling feet
6 – Granite top
7 – GN gastronomic containers
8 – Shelf in the container
9 – Door pulled apart
10 – Data plate
11 – Display cabinet control panel
12 – Wind brace (after dismounting access to condenser lamellas)
1 - Device levelling feet
2 - Wheel set (A – moving position;
B – blocked position)
Fig.3 Layout of GN containers
Fig.2 stationary and moving system
