3 - 10 3. INSTALLATION AND CONNECTION
BS-79 BS-79 0212 VOL1 (U) (E)
[TALLY OUT connector]
A
B
C
D
E
+12 V OUT
R TALLY
C TALLY
G TALLY
TALLY GND
+12 V power output
R TALLY output
COMM TALLY output
G TALLY output
Ground for tally signals
OUT
OUT
OUT
OUT
GND
This connector is used to output tally control signals.
BS side : PRC05-RB5F1 (Tajimi)
Cable side : PRC05-P5M (5-pin male plug)
or equivalent
• COMMON TALLY OUT can be used to control R and G tally signals simultaneously.
Insertion side
Pin Number Name Function Direction External Interface
Receptacle
A
B
C
D
B
C
D
A
B
C
D
E
R TALLY
G TALLY
+ V
or
B
C
D
E
