ILX Lightwave LDX-36000 Series User Manual

INTRODUCTION AND SPECIFICATIONS
Specifications
8 LDX-36000 Series
CHAPTER 1

36010-12 36025-12 36050-12 36085-12 36125-12
Duty Cycle
Pulse Mode 0.5 to 20% 0.5 to 20% 0.5 to 20% 0.5 to 20% 0.5 to 10%
HPulse Mode 20 to 90% 20 to 90% 20 to 90% 20 to 90% 10 to 90%
Resolution 0.1% 0.1% 0.1% 0.1% 0.1%
Rise / Fall Time
12
Pulse Mode <10 s <10 s<20 s<20 s<20 s
HPulse Mode 200 s 200 s 200 s 200 s 200 s
Overshoot
13
<2%<2%<2%<2%<2%
VOLTAGE LIMIT
14
Range 0 - 14.0 V 0 − 14.0 V 0 − 14.0 V 0 − 14.0 V 0 − 14.0 V
Resolution 100 mV 100 mV 100 mV 100 mV 100 mV
Accuracy
11
+1%+200mV +1%+200mV +1%+200mV +1%+200mV +1%+200mV
CURRENT LIMIT
Range CW 0 to 10.5A 0 to 26.2A 0 to 52.5A 0 to 89.2A 0 to 131.2A
Range QCW 0 to 22.0A 0 to 53.5A 0 to 106.0A 0 to 179.5A 0 to 232.0A
Range HPulse 0 to 10.5A 0 to 26.2A 0 to 52.5A 0 to 89.2A 0 to 131.2A
Resolution 10 mA 10 mA 100 mA 10 mA 10 mA
Firmware Limit Accuracy
15
+0.1%+10mA +0.1%+10mA +0.1%+20mA +0.1%+80mA +0.1%+120mA
Hardware Limit Accuracy
15
+1%+10mA +1%+10mA +1%+20mA +1%+80mA +1%+120mA
EVENT TRIGGERING (ALL MODELS)
Trigger Output
16
TTL Level; active high
Pulse Width 10 s
Delay Programmable
Accuracy 2 s +
0.05%
Range 0 s to 1s
Resolution 0.01% + 5 s
Jitter 100 ns
Trigger Input
17
TTL Level; rising edge triggered, single shot to 1 KHz; high impedance
Delay to Output Programmable
Accuracy 2 s +
0.05%
Range 20 s to 1s
Resolution 0.01% + 5 s
Jitter 200 ns
Pulse Trigger Output TTL Level, high impedance, active high
Table 1.2 LDX-36000 Series Specifications (Continued) (Sheet 2 of 8)
