ILX Lightwave LDX-36000 Series User Manual

INTRODUCTION AND SPECIFICATIONS
Specifications
03_10 LDX-36000 Series 9
CHAPTER 1

36010-12 36025-12 36050-12 36085-12 36125-12
MEASUREMENT
Forward Voltage
Range 0 to 12.00V 0 to 12.00V 0 to 12.00V 0 to 12.00V 0 to 12.00V
Resolution 10 mV 10 mV 10 mV 10 mV 10 mV
Accuracy
18
+0.05% +20mV
+0.05% +20mV +0.05% +20mV +0.05% +20mV +0.05% +20mV
Photodiode Current
Range 3 to 10000A 3 to 10000A 3 to 10000A 3 to 10000A 3 to 10000A
Resolution 3 A 3 A3 A3 A3 A
Accuracy
19
+0.1% +0.1% +0.1% +0.1% +0.1%
Reverse Bias
Range 0 to -15 V 0 to -15 V 0 to -15 V 0 to -15 V 0 to -15 V
Resolution 100 mV 100 mV 100 mV 100 mV 100 mV
Accuracy +
2.5% FS +2.5% FS +2.5% FS +2.5% FS +2.5% FS
PD Responsivity
Range
20
(mA/W)
0.001 to 100.00 0.001 to 100.00 0.001 to 100.00 0.001 to 100.00 0.001 to 100.00
Resolution (mA/W) .001 .001 .001 .001 .001
Power Control Range
Range 0 to 1000W 0 to 1000W 0 to 1000W 0 to 1000W 0 to 1000W
Resolution 1W 1W 1W 1W 1W
P1 (Slope Efficiency)
Range (W/A) 0.00 to 10.00 0.00 to 10.00 0.00 to 10.00 0.00 to 10.00 0.00 to 10.00
Resolution (W/A) 0.01 0.01 0.01 0.01 0.01
P2 (Threshold)
Range (W/A) 0.00 to 10.00 0.00 to 25.00 0.00 to 50.00 0.00 to 85.00
0.00 to 125.00
Resolution (W/A) 0.01 0.01 0.1 0.1 0.1
Temperature
Sensor Type 10K Thermistor
Range 0 to +199.9
o
C
Thermistor Current 100 A 100 A 100 A 100 A 100 A
Accuracy
21
+0.2
o
C
LASER DIODE PROTECTION
Output shorting relay, normally closed
2s turn-on delay (per 21CFR 1040.10)
Hardware Fault Response Time
24
Current Limit: <2 s
Open Circuit: <50 s
Intermittent contact protection
Table 1.2 LDX-36000 Series Specifications (Continued) (Sheet 3 of 8)
