ILX Lightwave LDX-36000 Series User Manual

INTRODUCTION AND SPECIFICATIONS
Specifications
10 LDX-36000 Series
CHAPTER 1

36010-12 36025-12 36050-12 36085-12 36125-12
AC power failure / brown-out detection; error monitoring and reporting
Transient protection: output on/off, power up/down, EFT/surge, 1000V
Adjustable current and voltage limit; redundant hardware current and voltage limit
INTERLOCKS
Interlock 1 Normally open, close to enable output
Interlock 2 Normally open, close to enable output
Fault Response Time
22
<6 ms
GENERAL
GPIB Interface IEEE/488
On-Board Memory Storage 1000 points
On-Board Upload Rate 30 ms/point
Power Requirements 100/240 VAC +
10%
100/240 VAC +
10%
100/240 VAC +
10%
220/240 VAC +
10%
220/240 VAC +
10%
Maximum Current Draw 4A/2A 6A/3A 10A/5A 15A/7.5A 20A/10A
Size (H x W x D)
23
146mm x 483mm x 451mm (5.25” x 19” x 17.75”)
Weight
10.9 kg/24 lbs
11.9 kg/26 lbs 11.9 kg/26 lbs 13.5 kg/30 lbs 15.2 kg/34 lbs
Operating Temperature 0
o
C to 40
o
C
Storage Temperature -40
o
C to 70
o
C
Humidity 20 - 85% non-condensing
Safety EN60950 Low Voltage Directive; 21CFR 1040.10
Regulatory Compliance CE Certified
CE EN61326-1: 2006 Basic Requirements; Immunity
EN55011:1007 Radiated and Conducted Emissions
EN61010-1: Safety Requirements
Connectors
Current Output Hybrid D-sub Hybrid D-sub Hybrid D-sub Bus Bar Bus Bar
Measurement DB 9 rear panel
Interlocks Terminal block
Pulse Trigger Out BNC rear panel
Input/Output Trigger BNC front panel
Table 1.2 LDX-36000 Series Specifications (Continued) (Sheet 4 of 8)
