5. COMPOSITION OF THE KIT
The here described kit is available in two
versions:
- Standard with extension “_01”;
- Coin-op with extension “_02”.
- K2950SCHEDESS_01 (standard)
ITEM
DESCRIPTION
Q.TY
6111105B
ES 10/34 IM7 box wiring
1
4141103X
ECC>IM7 Keypad std
1
2141141
ECC>IM7 Keypad support
1
2950DISESIM7
IM7 Display board
1
2950DISTA015
Rounded spacer
Nylon F/F L=15mm
4
4936RGZ10X30
Washer Fe 10x30x2.5
ZINB
4
4936DAF003M
Self-Locking Nut
DIN 982 M3 ZINB
4
6141102X
Wiring to convert
ECC – IM7
1
2950SENSOPT1
Temperature Probe
PT1000 Class B
1
6110807X
Flat Cable IM7>Display
10-20 PIN ES 10/34
1
1936FERCAVNY
Cable Fastener in Nylon
Richco
3
4936VITBO516
Screw TBEI INOX M5X16
4
4936RPZ0005M
Washer Fe 5 ZINB
4
4936DAFA005M
Self-Locking Nut
Din 982 M5 Zinb
4
2950CONMA02V
Two ways male connector
Mate-N-Lock
1
2950GU643TER
Shrinkt Tubing D.6,4/4,2
NE
50 cm
4936FASSN14B
Clamps NB 14B
1
2950FASCV140
Cable Tye 140x2.5 Cod.
CV – 140S
10
2950GVS15018
Silicon tube
140x2.5cod.CV-14S
10 cm
2950MORSP025
Borne Mammuth 2 ways
2
4936VAN3913Z
Self-Treating Screw
ZN 3,9x13 UNI 7981
3
E100301X_ENG
IM 7 User notice
1
E141203X
These instructions
1
- K2950SCHEDESS_02 (Coin Op)
ITEM
DESCRIPTION
Q.TY
6111105B
ES 10/34 IM7 box wiring
1
4141102X
ECC>IM7 Keypad Coin
1
2141141
ECC>IM7 Keypad support
1
2950DISESIM7
IM7 Display board
1
2950DISTA015
Rounded spacer
Nylon F/F L=15mm
4
4936RGZ10X30
Washer Fe 10x30x2.5
4
ZINB
4936DAF003M
Self-Locking Nut
DIN 982 M3 ZINB
4
6141102X
Wiring to convert
ECC – IM7
1
2950SENSOPT1
Temperature Probe
PT1000 Class B
1
6110807X
Flat Cable IM7>Display
10-20 PIN ES 10/34
1
1936FERCAVNY
Cable Fastener in Nylon
Richco
3
4936VITBO516
Screw TBEI INOX M5X16
4
4936RPZ0005M
Washer Fe 5 ZINB
4
4936DAFA005M
Self-Locking Nut
Din 982 M5 Zinb
4
2950CONMA02V
Two ways male connector
Mate-N-Lock
1
2950GU643TER
Shrinkt Tubing D.6,4/4,2
NE
50 cm
4936FASSN14B
Clamps NB 14B
1
2950FASCV140
Cable Tye 140x2.5 Cod.
CV – 140S
10
2950GVS15018
Silicon tube
140x2.5cod.CV-14S
10 cm
2950MORSP025
Borne Mammuth 2 ways
2
4936VAN3913Z
Self-Treating Screw
ZN 3,9x13 UNI 7981
3
6111123X
Additional Cabling IM7 for
Coin box
1
E100301X_ENG
IM 7 User notice
1
E141203X
These instructions
1
6. 2950SCHEDESS_01 INSTALLATION
OF ELECTRONICS PART
Before to service the machine, it must be
completely switch off and the temperature
must be the room temperature. Suppling
cable must be disconnected from the plug
and from the electric board. Compressed
air and gas supply, if provided, must also
be disconnected.
a) Open the above frontal cover, open the
filter door, remove the above cover (if
present), remove the back panels;
b) The ECC board is placed inside the
programmer box, together with the display
and the keypad.
