Upper roller for simultaneous cutting of several bars- it is an optional - together with the vertical vice, it
allows to move and to lock a group of bars suitably prepared, or tubulars placed side by side ( not one on the
other ) . The maximum dimensions that can be reached are : width 280 mm., height .100. mm., 20 mm.
minimum.
Additional supporting roller for the feeding - it increases the support of the material to cut ( when the bar
is almost finished ). You can assemble it and dismantle with great ease.
Hydraulic vertical vices for cutting bundles, connected to the standard vices. They allow to clamp and feed a
bundle of bars – maximum breadth 250mm, minimum breadth 110mm, maximum height 120 mm.
Minimal lubrication system – This device, applied to the saw, allows to eliminate almost completely the
traditional coolant system, keeps the material much cleaner and avoids to waste cutting oil and water. It
works only during the cut.
It is comprised of a nozzle - 1/RI0463 - with 3 micro-holes, a tank with devices to adjust the quantity of oil and
the air pressure. The switch of the electric system - 3/RI0462 - working with low tension 24V AC allows to turn
it off at any moment and use the normal coolant system. . Remove the nozzle 1/RI0463 to obtain the maximal
cutting capacity.
