Specifications and Performance
General
Frequency Range (for acceleration)
(operating, 100 gram payload)
5 Hz – 10 kHz
300 CPM - 600k CPM
Maximum Amplitude
(100 Hz, no payload)
20 g pk
196 m/s
2
pk
15 in/s pk
380 mm/s pk
50 mils pk - pk
1.27 mm pk – pk
Maximum Payload
[1]
800 gram
[1] Operating range reduced at higher payloads. Reference shaker loading curves
for full details
Accuracy of Readout
measured with 10 gram quartz reference accelerometer
Acceleration (10 Hz to 10 kHz)
± 3%
Acceleration (5 Hz to 10 kHz)
± 5%
Velocity (10 Hz to 1000 Hz)
± 3%
Displacement (30 Hz to 150 Hz)
± 3%
Amplitude Linearity (100 gram payload, 100 Hz)
< 1% up to 10 g pk
Waveform Distortion
(100 gram payload, 30 Hz to 2 kHz)
< 5% THD (typical) up to 5 g pk
Units of Readout
Acceleration (peak/RMS)
g
m/s
2
Velocity (peak/RMS)
in/s
mm/s
Displacement (peak to peak)
mils
µm
Frequency
Hz
CPM
Test Sensor Sensitivity
mV/EU
[2]
[2] EU can be [g], [m/s
2
], [in/s], [mm/s], [mils] or [µm].
