IMI SENSORS 699A07 User Manual

Model Number
699A07
PORTABLE VIBRATION CALIBRATOR
Revision: A
ECN #: 48972
Performanc
e
ENGLISH S
I
Maximum Load 800 gm 800 gm
[4]
Frequency Range(operating, 100 gram payload) 5 to 10,000 Hz 300 to 600,000 cpm
Accuracy(10 Hz to 10 khz) ± 3 % ± 3 %
Accuracy(5 Hz to 10 Hz) ± 5 % ± 5 %
Accuracy(Velocity (10 Hz to 1000 Hz)) ± 3 % ± 3 %
Accuracy(Displacement (30 Hz to 150 Hz)) ± 3 % ± 3 %
Amplitude Linearity(100 gram payload, 100 Hz) 1 % 1 %
[5]
Distortion
(
100
g
ram
p
a
y
load, 30 Hz to 2 kHz
)
<5 % <5 %
[6]
Maximum Am
p
litude
(
Acc 100 Hz no
p
a
y
load
)
20
g
pk
196 m/s^2
pk
Maximum Amplitude(Vel 100 Hz no payload) 15 in/sec p
k
380 mm/s p
k
Maximum Amplitude(Displ 100 Hz no payload) 50 mils pk-pk 1.27 mm pk-pk
Control Interfac
e
Test Sensor In Voltage or ICP® Voltage or ICP®
[1]
Bias Fault Indication (ICP® Sensors) Yes Yes
External Source In (Max) 1V AC RMS 1V AC RMS
Monitor Reference Out
10 mV/g (nominal),
Buffered internal
reference output
10 mV/g (nominal),
Buffered internal
reference output
Display Units(Acceleration) g pk & RMS m/s² pk & RMS
Dis
p
la
y
Units
(
Velocit
y)
in/sec
p
k & RMS mm/sec
p
k & RMS
Displa
y
Units
(
Displacement
)
mils p
k
-p
k
um p
k
-p
k
Display Units(Frequency) Hz CP
M
Test Sensor Sensitivity mV/EU mV/EU
[2]
Environmenta
l
Temperature Range(Operating) 32 to 122 °F 0 to 50 °C
Electrica
l
Power Required(Internal Battery (sealed solid gel lead acid)) 12 VDC, 4 amp hours 12 VDC, 4 amp hours
Power Required(AC Power (for recharging battery)) 110-240 V, 50-60 Hz 110-240 V, 50-60 Hz
Battery Life(100 gram payload, 100 Hz 1g pk) 18 hours 18 hours
[3]
Battery Life(100 gram payload, 100 Hz 10g pk) 1 hour 1 hour
[3]
Ph
y
sica
l
Storage
Up to 500 calibration
records
Up to 500 calibration
records
Points Per Record
30 calibration data
points
30 calibration data
points
Sensor Information
Model number, serial
number, Mounting
orientation (x, y, z), user
notes
Model number, serial
number, Mounting
orientation (x, y, z), user
notes
Export File Format
CSV (comma-separated
values)
CSV (comma-separated
values)
USB Port
Export to flash drive
(FAT 32)
Export to flash drive
(FAT 32)
Size (Depth x Height x Width) 10 in x 8.5 in x 12 in
28 cm x 22 mm x 30.5
cm
Weight(with batteries) 18 lb 8.2 k
g
Mounting Thread 1/4-28 Female No Metric Equivalent
All specifications are at room temperature unless otherwise specified.
In the interest of constant product improvement, we reserve the right to change specifications without notice.
ICP
®
is a registered trademark of PCB Group, Inc.
OPTIONAL VERSIONS
Optional versions have identical specifications and accessories as listed for the standard model
except where noted below. More than one option may be used.
NOTES
:
[1] 5 mA constant current excitation to ICP® (IEPE) sensor.
[
2
]
EU can be
[g]
,
[
m/s²
]
,
[
mm/s
]
,
[
in/s
]
,
[
mils
]
or
[
um
]
[3] As shipped from factory in new condition
[
4
]
O
p
eratin
g
ran
g
e reduced at hi
g
her
p
a
y
loads. Reference manual for full details
.
[5] Up to 10g pk
[6] Up to 5g p
k
SUPPLIED ACCESSORIES:
Model 080A118 Mounting pad 1.0" diameter 1/4-28 tapped hole (for stud mounting
accelerometers) (1)
Model 081A08 Mounting Stud (10-32 to 1/4-28) (1)
Model 081B20 Mounting Stud, with shoulder (1/4-28 to 1/4-28) (1)
Model 600A25 Power Supply and Plug Adaptors (1)
Model 600A34 Mounting Wrench (1)
Model ICS-41 NIST traceable Certificate of Calibration, Metric & English Units (1)
Model USB DRIVE Flash Drive with Calibration Re
p
ort Generation Worksheet
(
1
)
OPTIONAL ACCESSORIES:
Model 600A31 Calibration route semi-automation & pass/fail notification (1)
Model 600A33 Modulated current sensors power supply and measurement: Test Sensor
Sensitivity units of readout are mV/EU, mA/EU or uA/EU, Test Sensor Input/output Voltage, ICP
or Modulated current. Includes USB to 24 VDC power supply (600A39). (1)
Entered: LK Engineer: NJF Sales: M
C
Approved: NJF Spec Number:
Date: 12/18/2018 Date: 12/18/2018 Date: 12/18/201
8
Date: 12/18/2018
66697
3425 Walden Avenue, Depew, NY 14043
Phone: 800-959-4464
Fax: 716-684-3823
E-Mail: imi@pcb.com
