Vertical kit with aluminium tile Ø 80/125. Kit
assembly (Fig. 1-19): install the concentric ange
(2) on the central hole of the boiler inserting the
gasket (1) and tighten using the screws in the
kit. Fit the male end (smooth) of the adapter (3)
into the female end of the concentric ange (2).
Imitation aluminium tile installation. Replace
the tile with the aluminium sheet (5), shaping
it to ensure that rainwater runs o. Position
the xed half-shell (7) on the aluminium tile
and insert the intake-exhaust pipe (6). Fit the Ø
80/125 concentric terminal pipe with the male
end (6) (smooth) to the female end of the adapter
(3) (with lip gasket) up to the stop; making sure
that the wall sealing plate has been tted, this
will ensure sealing and joining of the elements
making up the kit.
• Coupling extension pipes and concentric
elbows. To install push-tting extensions with
other elements of the ue extraction elements
assembly, proceed as follows: engage the
concentric pipe or elbow with the male side
(smooth) on the female section (with lip seal)
up to the stop on the previously installed ele-
ment. is will ensure sealing and joining of
the elements correctly.
Important: if the exhaust terminal and/or exten-
sion concentric pipe needs shortening, consider
that the internal pipe must always protrude by
5mm with respect to the external pipe.
is specic terminal enables ue exhaust and
air intake, necessary for combustion, in a verti-
cal direction.
N.B.: e Ø 80/125 vertical kit with aluminium
tile enables installation on terraces and roofs
with a maximum slope of 45% (25°) and the
height between the terminal cap and half-shell
(374 mm) must always be respected.
e vertical kit with this conguration can be
extended up to a maximum of 12,200 mm vertical
rectilinear, with the terminal included (Fig. 1-20).
is conguration corresponds to a resistance
factor of 100. In this case the special extensions
must be requested.
The terminal Ø 60/100 can also be used for
vertical exhaust, in conjunction with concentric
flange code 3.011141 (sold separately). The
height between the terminal cap and half-shell
(374 mm) must always be respected.
The vertical kit with this configuration can
be extended up to a maximum of 4,700 mm
vertical rectilinear, with the terminal included
(Fig.1-20).
Separator kit Ø 80/80. e Ø 80/80 separator
kit, allows separation of the exhaust ues and
air intake pipes according to the diagram shown
in the gure. Combustion products are expelled
from pipe (S). Air is taken in through pipe (A)
for combustion. The intake pipe (A) can be
installed either on the right or le hand side of
the central exhaust pipe (S). Both ducts can be
routed in any direction.
• Kit assembly (Fig. 1-21): install ange (4) on the
central hole of the boiler, tting gasket (1) and
tighten with the at-tipped hex screws included
in the kit. Remove the at ange present in the
lateral hole with respect to the central one (ac-
cording to needs) and replace it with the ange
(3), positioning the gasket (2) already present in
the boiler and tighten using the supplied self-
threading screws. Fit the male end (smooth) to
the bends (5) in the female end of the anges
(3 and 4). Fit the intake terminal (6) with the
e kit includes:
N°1 - Gasket (1)
N°1 - Concentric bend Ø 60/100 (2)
N°1 - Adapter Ø 60/100 for Ø 80/125 (3)
N°1 - Int./exhaust concentric terminal
Ø 80/125 (4)
N°1 - Internal wall sealing plate (5)
N°1 - External wall sealing plate (6)
e kit includes:
N°1 - Gasket (1)
N°1 - Female concentric ange (2)
N°1 - Adapter Ø 60/100 for
Ø 80/125 (3)
N°1 - Wall sealing plate (4)
N°1 - Aluminium tile (5)
N°1 - Concentric intake-exhaust
terminal Ø 80/125 (6)
N°1 - Fixed half-shell (7)
N°1 - Mobile half-shell (8)
MAXIMUM LENGTH 4700 mm
MAXIMUM LENGTH 12200 mm
