1.1 INSTALLATION
RECOMMENDATIONS.
e Mini Eolo 28 3 E boiler has been designed
for wall mounted installation; they must be used
to heat environments, to produce domestic hot
water and similar purposes. In the case of wall
installation the wall surface must be smooth,
without any protrusions or recesses enabling
access to the rear part. ey are NOT designed
to be installed on plinths or oors (Fig. 1-1).
By varying the type of installation the classica-
tion of the boiler also varies, precisely:
- Boiler type B22 if installed without the 2 intake
caps and with the top cover kit
- Type C boiler if installed using concentric
pipes or other types of pipes envisioned for
the sealed chamber boiler for intake of air and
expulsion of fumes.
Only professionally qualied heating/plumbing
technicians are authorised to install Immergas
gas appliances. Installation must be carried out
according to the standards, current legislation
and in compliance with local technical regula-
tions and the required technical procedures.
Installation of the Mini Eolo 28 3 E boiler when
powered by LPG must comply with the rules
regarding gases with a greater density than air
(remember, as an example, that it is prohibited to
install plants powered with the above-mentioned
gas in rooms where the oor is at a lower quota
that the average external country one).
Attention: the manufacturer declines all liability
for damages caused by boilers removed from
other systems or for any non-conformities of
such equipment.
Before installing the appliance, ensure that it is
delivered in perfect condition; if in doubt, contact
the supplier immediately. Packing materials (sta-
ples, nails, plastic bags, polystyrene foam, etc.)
constitute a hazard and must be kept out of the
reach of children. If the appliance is installed in-
side or between cabinets, ensure sucient space
for normal servicing; therefore it is advisable to
leave clearance of at least 3 cm between the boiler
casing and the vertical sides of the cabinet. Leave
adequate space above the boiler for possible water
and ue removal connections.
Keep all ammable objects away from the ap-
pliance (paper, rags, plastic, polystyrene, etc.).
Do not place household appliances underneath
the boiler as they could be damaged if the
safety valve intervenes (if not conveyed away by
a discharge funnel), or if there are leaks from
the connections; on the contrary, the manufac-
turer cannot be held responsible for any damage
caused to the household appliances.
In the event of malfunctions, faults or incorrect
operation, turn the appliance o immediately and
contact a qualied technician (e.g. the Immergas
Technical Aer-Sales Centre, which has speci-
cally trained sta and original spare parts) Do not
attempt to modify or repair the appliance alone.
Failure to comply with the above implies personal
responsibility and invalidates the warranty.
• Installation regulations: this boiler can be in-
stalled outside in a partially protected area. A
partially protected location is one in which the
appliance is not exposed to the direct action of
the weather (rain, snow, hail, etc.).
Important: Wall mounting of the boiler must
guarantee stable and ecient support for the
generator.
e plugs (standard supply) are to be used only in
conjunction with the mounting brackets or xing
template to x the appliance to the wall; they only
ensure adequate support if inserted correctly (ac-
cording to technical standards) in walls made of
solid or semi-hollow brick or block. In the case of
walls made from hollow brick or block, partitions
with limited static properties, or in any case walls
other than those indicated, a static test must be
carried out to ensure adequate support.
N.B.: the hex head screws supplied in the blister
pack are to be used exclusively to x the relative
mounting bracket to the wall.
ese boilers are used to heat water to below
boiling temperature in atmospheric pressure.
ey must be attached to a heating system suit-
able for their capacity and voltage.
