8
VXS40-1 and VXS75-1 (Single Phase)
VXS40-3 and VXS75-3 (Three Phase)
PANEL
CONTROL
PRG MODE RUN
Hz A V
r/min m/min
PRG
RESET
RUN
FUNC
DATA
STOP
*Centrelines of 3 cable entry holes, 22mm dia.
30
30
128
140
5
6
6
6
6
Dimensions in mm
138
150
2 holes, 5mm
46
6
109
75
*** *
Removable
side-cover
PANEL
CONTROL
PRG MODE RUN
Hz A V
r/min m/min
PRG
RESET
RUN
FUNC
DATA
STOP
30
30
188
200
5
6
6
6
6
Dimensions in mm
138
150
71
6
100
134
VXS150-1 and VXS220-1 (Single Phase)
VXS150-3 and VXS220-3 (Three Phase)
*Centrelines of 3 cable entry holes, 22mm dia.
*** *
2 holes, 5mm
Removable
side-cover
4.6 Dimensions continued
