Motor overheats
NO
Do
motor and V/f patterns
match
?
YES
NO
Does
motor operate
long periods at low
speeds
?
YES
Motor
overheating
Change set points
of Functions
04 or 62, 05,
and 08 or 65
Malfunction
of motor.
NO
Is
load too
high
?
YES
Increase motor
and inverter
frame sizes
NO
Is
output (U, V, W)
voltage balanced
?
YES
Possible
malfunction
of inverter.
Consult IMO
Derate motor
and/or apply
forced cooling
?
STATUS QUERY ACTION
