Chapter8 Communication Function
8-15
(4) Response format (NAK response)
Format name Header Station No. Command Command type
Error code
(Hex 2 Byte)
Tail Frame check
Ex. of frame
NAK H10 r SB H1132 ETX BCC
ASCII value
H15 H3130 H72 H5342 H31313332 H03
Item Explanation
BCC
When command is lowercase(r), only one lower byte of the value resulted by adding 1 Byte
each to ASCII values from NAK to ETX is converted into ASCII and added to BCC, and sent.
Error code
Hex and 2 bytes(ASCII code, 4 bytes) indicate error type. For the details, see 8.1.8 Error
codes.
(5) Example
This example supposes that 2 WORDs from M000 of station No. 10 is read and BCC value is checked.
Also it is supposed that data in M000 and in M001 is as follow:
M000 = H1234
M001 = H5678
①
Computer request format (PC
→
MK80S Base Unit)
Format name Header Station No. Command
Command
type
Device length Device name Number of data Tail Frame check
Frame (Example) ENQ H0A r SB H06 %MW000 H02 EOT BCC
ASCII value H05 H3041 H72 H5342 H3036
H254D5730
3030
H3032 H04
②
For ACK response after execution of command(PC
←
MK80S Base Unit)
Format name Header Station No. Command
Command
type
Number of
data
Data Tail Frame check
Frame (Example) ACK H0A r SB H04 12345678 ETX BCC
ASCII value H06 H3041 H72 H5342 H3034 H3132333435363738 03
③
For NAK response after execution of command(PC
←
MK80S Base Unit)
Format name Header Station No> Command Command type
Error code Tail BCC
Frame (Example) NAK H0A r SB Error code (2Byte) ETX BCC
ASCII value H15 H3041 H72 H5342 Error code (4Byte) H03
