Chapter 5 CPU Module
5-
ైౌ
5.8 Built-in Flash Memory
K7 series includes a built-in flash memory to store user program. Also, user can set the PLC automatically executes the user
program of flash memory when the PLC is turned on. It is similar with the ROM operation of other PLCs, but it is different that no
external memory is required.
5.8.1 Structure
You can see dip switches as shown when you open I/O terminal block cover.
BUILT_IN CNET
ON
ROM MODE
OFF
Terminal block cover
To Next Page
