Chapter 5 CPU Module
5-
ైె
5.5.2 I/O Force On/Off function
It is possible to input/output a designated data regardless of the result of program operation. This function is useful to check
operation of the input/output modules and wiring between the output modules and external devices.
1) Force On/Off setting method.
Force on/off setting is applied to input area and output area.
Force on/off should be set for each input and output, the setting operates from the time that Force I/O setting enable’ is set.
This setting can be done when I/O modules are not really loaded.
Select the ’ set forced I/O’ from KGLWIN
Select the I/O area and then double click.
Click
To Next Page
