IMO Precision Controls K7 Series User Manual

Chapter8 Communication Function
8-18
(5) Example
This example supposes that "HFF" is written in M230 of station No. 1 and BCC value is checked.
①
Computer request format(PC
→
K7 Base Unit)
Format name Header Station No. Command
Command
type
Number of
blocks
Device Length Device Name Data
Tail
Frame
check
Frame (Example) ENQ H01 w SS H01 H06 %MW230 H00FF EOT BCC
ASCII value H05 H3031 H77 H5353 H3031 H3036
H254D5732
3330
H30304646 H04
②
For ACK response after execution of command(PC
←
K7 Base Unit)
Format name Header Station No. Command Command type
Tail Frame check
Frame (Example) ACK H01 w SS ETX BCC
ASCII value H06 H3031 H77 H5353 H03
③
For NAK response after execution of command(PC
←
K7 Base Unit)
Format name Header Station No. Command Command type
Error code Tail Frame check
Frame (Example) NAK H01 w SS Error code (2) ETX BCC
ASCII value H15 H3031 H77 H5353 Error code (4) H03
