Chapter8 Communication Function
8-27
(5) Example
This example supposes that registered device No. 1 of station No. 1 is read. and BCC value is checked.
And it is supposed that device M000 is registered and the number of blocks is 1.
x Computer request Format(PC
→
K7 Base Unit)
Format name Header Station No. Command
Registration No. Tail Frame check
Frame (Example) ENQ H01 y H01 EOT BCC
ASCII value H05 H3031 H79 H3031 H04
y For ACK response after execution of command (PC
←
K7 Base Unit)
Format name Header Station No. Command
Registration
No.
Number of Blocks
Number of
data
Data Tail
Frame
check
Frame (Example) ACK H01 y H01 H01 H04 H23422339 ETX BCC
ASCII value H06 H3031 H79 H3031 H3031 H3034
H3233343232
333339
H03
z For NAK response after execution of command (PC
←
K7 Base Unit)
Format name Header Station No. Command
Registration No. Error code Tail Frame check
Frame (Example) NAK H01 y H01 Error code (2) ETX BCC
ASCII value H15 H3031 H79 H3031 Error code (4) H03
