Chapter 2 System Configuration
2-5
2.2.2 K80S Series System Equipment
Section Items Models Description Remark
K7M-DR20S
• I/O Points
- 12 DC inputs / 8 relay outputs
• Program capacity : 48 kbytes
• Built-in function
-High-speed counter : Phase1 16 kHz, phase2 8 kHz 1channel
-pulse output : 1
ለ
2 kHz
-pulse catch : pulse width 0.2ms, 4 points
-external contact point interrupt: 0.4ms, 8points
-input filter: 0 ~ 15ms (all input )
-PID control function
-RS-232C communication
Under
development
K7M-DR30S
• I/O Points
- 18 DC inputs / 12 relay outputs
• Program capacity : 48 kbytes
• Built-in function
-High-speed counter : Phase1 16 kHz, phase2 8 kHz 1channel
-pulse output : 1
ለ
2 kHz
-pulse catch : pulse width 0.2ms, 4 points
-external contact point interrupt: 0.4ms, 8points
-input filter: 0 ~ 15ms (all input )
-PID control function
-RS-232C communication
K7M-DR40S
• I/O Points
- 24 DC inputs / 16 relay outputs
• Program capacity : 48 kbytes
• Built-in function
-High-speed counter : Phase1 16 kHz, phase2 8 kHz 1channel
-pulse output : 1
ለ
2 kHz
-pulse catch : pulse width 0.2ms, 4 points
-external contact point interrupt: 0.4ms, 8points
-input filter: 0 ~ 15ms (all input )
-PID control function
-RS-232C communication
Basic Base Unit
K7M-DR60S
• I/O Points
- 36 DC inputs / 24 relay outputs
• Program capacity : 48 kbytes
• Built-in function
-High-speed counter : Phase1 16 kHz, phase2 8 kHz 1channel
-pulse output : 1
ለ
2 kHz
-pulse catch : pulse width 0.2ms, 4 points
-external contact point interrupt: 0.4ms, 8points
-input filter: 0 ~ 15ms (all input )
-PID control function
-RS-232C communication
