IMO Precision Controls K7 Series User Manual

Chapter 7 Usage of Various Functions
7-
ై
3) Names of wiring terminals
No.
Terminal No. Names Usage
ᐭ
P00
φA 24V
A Phase input terminal
ᐮ
P01
φB 24V
B Phase input terminal
ᐯ
P02
Preset 24V
Preset input terminal
ᐰ
COM0 Common input
Common terminal
4) External interface circuit
I/O Internal circuit
Terminal
No.
Signal name
Operation
Input warranted
voltage
On 14 ~ 26.4 V
P00
A-phase pulse
Input (DC24V)
Off 2.5V or lower
On 14 ~ 26.4 V
P01
B-phase pulse
Input (DC24V)
Off 2.5V or lower
Input
COM0
COM
(input common)
On 19 ~ 26.4 V
P02
Preset input
(DC24V)
Off 6V or lower
Input
COM0
COM
(input Common)
1.
5
KΩ
8
2
0
Ω
1.5 kΩ
1.5 kΩ
8
2
0
Ω
820 Ω
BUILT_IN CNET
ON
ROM MODE
OFF
P00
P01
P02
P03
P04
ᐭᐮᐯ
Counter in
p
ut
Preset input
ᐰ
24G
COM0
24V
P12
P0C
P1A
P0BP09P05
I05
