5-40
If P99 (Motor characteristics) is set to 0 (Standard motors), 3 (Conventional motors), or 4 (Other
motors):
Rated current (A) Setting
range
(kW)
If P99 (Motor selection) is set to:
Power
supply
voltage
Function code
P02
Applicable
motor rating
(kW)
0 3 4
0.01 to 0.06 0.06 0.44 0.44 0.44
0.07 to 0.10 0.1 0.68 0.68 0.68
0.11 to 0.20 0.2 1.30 1.30 1.30
0.21 to 0.40 0.4 2.30 2.30 2.30
0.41 to 0.75 0.75 3.60 3.60 3.60
0.76 to 1.50 1.5 6.10 6.10 6.10
1.51 to 2.20 2.2 9.20 9.20 9.20
2.21 to 3.70 3.7 15.00 15.00 15.00
3.71 to 5.50 5.5 22.00 22.00 22.00
Three-phase 200V
Single-phase 200V
5.51 to 10.00 7.5 29.00 29.00 29.00
0.01 to 0.06 0.06 0.22 0.22 0.22
0.07 to 0.10 0.1 0.34 0.34 0.34
0.11 to 0.20 0.2 0.65 0.65 0.65
0.21 to 0.40 0.4 1.15 1.15 1.15
0.41 to 0.75 0.75 1.80 1.80 1.80
0.76 to 1.50 1.5 3.05 3.05 3.05
1.51 to 2.20 2.2 4.60 4.60 4.60
2.21 to 3.70 3.7 7.50 7.50 7.50
3.71 to 5.50 5.5 11.00 11.00 11.00
Three-phase 400V
5.51 to 10.00 7.5 14.50 14.50 14.50
NOTE: The above values in the "Rated current" column are applicable to four-pole standard motors rated
for 200 V and 400 V at 50 Hz. If you use non-standard motors, change the P02 data to the rated current
printed on the motor's nameplate.
