5-41
 If P99 (Motor characteristics) is set to 1 (HP motors):
Rated current (A) Setting
range
(HP)
If P99(Motor selection) is set to:
Power
supply
voltage
Function code
P02
Applicable
motor rating
(HP)
1
0.01 to 0.10 0.1 0.44
0.11 to 0.12
0.12 0.68
0.13 to 0.25
0.25 1.40
0.26 to 0.50
0.5 2.00
0.51 to 1.00
1 3.00
1.01 to 2.00
2 5.80
2.01 to 3.00
3 7.90
3.01 to 5.00
5 12.60
5.01 to 7.50
7.5 18.60
Three-phase 200V
Single-phase 200V
7.51 to 10.00 10 25.30
0.01 to 0.10 0.1 0.22
0.11 to 0.12
0.12 0.34
0.13 to 0.25
0.25 0.70
0.26 to 0.50
0.5 1.00
0.51 to 1.00
1 1.50
1.01 to 2.00
2 2.90
2.01 to 3.00
3 4.00
3.01 to 5.00
5 6.30
5.01 to 7.50
7.5 9.30
Three-phase 400V
7.51 to 10.00
10 12.70
NOTE: The above values in the "Rated current" column are exclusively appli-
cable to a four-pole standard motors rated for 200 V and 400 V at 60 Hz. If you
use non-standard or other manufacturer’s motors, change the P02 data to the
rated current printed on the motor's nameplate.
