IMT 2003i Parts & Specifications

Specications 6 Section - 2
4004i - Manual # 99904386
Load Capacity Chart (70397414)
BY
CAPACITY CHART -
IMT 4004i CRANE
4-14-08
IOWA MOLD TOOLING CO., INC
BOX 189, GARNER, IA 50438
TEL: 641-923-3711 FAX: 641-923-2424
TECH PUBS GENERATED DRAWING
DR AWN B Y
AP P R OVE D BY
DAT E
DAT E
S CALE
T ITL E
S IZ E DW G NO
PAT
A
FU L L
S H T OF
1 1
NOTES:
MATL: .OO5“ VELVET FINISH LEXAN
ADHESIVE: 3M 468 HI-PERFORMANCE APPLIED AFTER SCREENING
SIZE: 6”W x 8.5"H
COLORS: BLACK ON WHITE BACKGROUND, AS SHOWN
VENDOR: CREATIVE SCREEN PRINT (CRE10) OR EQUIV.
70397414
IOWA MOLD TOOLING CO., INC.
BOX 189, GARNER, IA 50438-0189
TEL: 641-923-3711 FAX: 641-923-2424
70397414
4004i CAPACITY CHART
75°
60°
45°
30°
15°
16'
4.8 m
4000
1815
4000
1815
3560
1615
2190
995
2940
1335
4000
1815
1710
775
2320
1050
3490
1585
3020
1370
1980
900
1450
660
1270
575
2680
1215
1080
490
1500
680
2330
1055
Maximum 1-part line
capacity is 2000 lb (907 kg).
For greater loads, use
2-part line.
NOTE: LBS/KG denote
2-part line.
14'
4.2 m
12'
3.6 m
10'
3.0 m
8'
2.4 m
6'
1.8 m
4'
1.2 m
2'
0.6 m
0
(Base)
16'
4.8 m
14'
4.2 m
12'
3.6 m
10'
3.0 m
8'
2.4 m
6'
1.8 m
4'
1.2 m
2'
0.6 m
0
ADDED WIRE ROPE INFORMATION
PER ASME B30 5-1.1.3
WIRE ROPE DATA:
DIAMETER; 0.25, NON-ROTATION RESISTANT, MINIMUM BREAKING LOAD; 7000,
MAXIMUM SINGLE LINE LOAD; 2000 lb (907 kg).
DISTANCE IN FEET/METERS / LOAD IN POUNDS/KG. WEIGHT OF LOAD HANDLING
DEVICES ARE PART OF THE LOAD LIFTED AND MUST BE DEDUCTED FROM THE CAPACITY.
REVISIONS
DESCRIPTIONECN/CNREV DATE
A 277 12-15-15 BKS

IMT 2003i Specifications

General

Brand	IMT
Model	2003i
Category	Construction Equipment
Language	English
