4004i Technical Data
GENERAL SPECIFICATIONS
CRANE RATING (crane rating (ft-lb) is the rated load (lb)
multiplied by the respective distance (ft) from centerline
of rotation with all extensions retracted and lower boom in
horizontal position.)
18,000 ft-lb at 8’-0” (2.5 tm at 2.4 m)
Horizontal Reach (From Centerline Of Rotation) 16’-0” (4.9 m)
Hydraulic Extension (1) 48” (122 cm)
Manual Extension (1) 48” (122 cm)
Lifting Height (From Base of Crane to Centerline of Sheave) 17’-2” (5.2 m)
Crane Weight (1H1m) 758 lb (344 kg)
Crane Storage Height 32” (81.3 cm)
Mounting Space Required (Crane Base) 14” x 18” (35.5 cm x 45.7 cm)
Hydraulic System Operating Pressure 2500 psi (172 Bar)
Maximum Hydraulic Flow 1.6 gpm (6 Lpm)
Oil Reservoir Capacity 1.5 gallons (5.7 L)
Oil Type ISO VG32, Low Pour, Anti-Wear Hydraulic Oil
CENTER OF GRAVITY
Horizontal from Centerline of Rotation (Booms Retracted) 32” (81.3 cm)
Horizontal from Centerline of Rotation (Booms Extended) 46” (116.8 cm)
Vertical from Bottom of Crane Base 16” (40.6 cm)
Tie-Down Bolt Pattern (On Center)
12” x 12” or 11.5” x 14.75”
(30.5 cm x 30.5 cm) or (29.2 cm x 37.5 cm)
Rotation Torque 3500 ft-lb
CYLINDER SPECIFICATIONS
Lower Boom Cylinder
3.5” bore; 16” stroke
(8.9 cm bore; 40.6 cm stroke)
Extension Boom Cylinder
1.5” bore; 48” stroke
(3.8 cm bore; 122.0 cm stroke)
WINCH SPECIFICATIONS
Winch Pull Line 2000 lb (907 kg)
Pull Line Speed Without Load 23 ft/min (7 m/min)
Rope Diameter 1/4” (6.35 mm)
Wire Rope Length 75’ (22.9 m)
Cable Nominal Strength 7000 lb (3175 kg)
PERFORMANCE CHARACTERISTICS
SPECIFICATIONS SPEED
Rotation 360º (Continuous) 44 seconds
Lower Boom Elevation -5º to +75º 10 seconds
Extension Cylinder 48” (122.0 cm) 10 seconds total
CHASSIS REQUIREMENTS
