General Information 104 Section - 6
4004i - Manual # 99904386
99904410 PARTS LIST
DECAL PLACEMENT (IF NOT SHOWN ON CRANE)
ITEM NO. PLACEMENT
15, 21, 23, 24,
28, 31, 35.
AT OR NEAR REMOTE HANDE STORAGE POINT
16. 2 ON REAR STABILIZERS
19. AT OR NEAR DRIVELINE
18, 20. ON SIDES AND REAR OF CARRIER VEHICLE
37, 38 . ON FRONT OF CARRIER VEHICLE
36.. ON CRANE POWER CABLE CONNECTION AT VEHICLE BATTERY
ITEM NO. PART NO. DESCRIPTION
KIT
NO.
QTY IN
KIT
QTY ON
CRANE
1. 95719347 DECAL KIT - TELE COMMON 1
2. 95719348 DECAL KIT - BODY COMMON 1
3. 95721547 DECAL KIT-4004I (IMT) 1
4. 70391612 DECAL-GREASE WEEKLY (LEFT) 1 9 0
5. 70391613 DECAL-GREASE WEEKLY (RIGHT) 1 6 0
6. 70392399 DECAL-LUBRICATE WORM 1 1 1
7. 70392524 DECAL-ROTATE CRANE WHILE GREAS 1 1 1
8. 70394166 DECAL-INSTR FOR MNL OPERATION 1 1 0
9. 70394443 DECAL-DANGER FREEFALLING BOOMS 1 1 1
10. 70395090 DECAL-GREASE WORM DR BRNGS 1 1 1
11. 70395324 DECAL-ASME/ANSI B30.5-TELESCOP 1 1 1
12. 70395670 DECAL-CAUTION DOWN HAUL WT 1 2 2
13. 71391522 DECAL-ANGLE INDICATOR RH 1 1 0
14. 71391523 DECAL-ANGLE INDICATOR LH 1 1 0
15. 70392213 DECAL-CAUTION DONT WASH/WAX 1 1 1
16. 70392864 DECAL-WARNING STAB STAND CLEAR 2 4 2
17. 70391598 DECAL-WARNING, MAN STAB 2 2 0
18. 70392868 DECAL-DANGER CR LOADLINE (TRK) 2 4 3
19. 70392891 DECAL-DANGER DRIVELINE 2 1 1
20. 70394445 DECAL-DANGER ELEC HZD LG TELES 2 4 3
21. 70396613 DECAL-CRANE SAFETY & OPER 2 1 1
22. 70394189 DECAL-MOBILOIL RESERVOIR 2 1 1
23. 71039134 DECAL-CAUTION OIL LEVEL 2 1 1
24. 70392982 DECAL-SERVICE & REPAIR 2 1 1
25. 71394083 DECAL-LOAD BLOCK RATING 2.0TON 3 2 2
26. 70399142 DECAL-DIAMOND IMT 4X8 3 2 2
27. 70396780 DECAL-IDENT 4004I 3 2 2
28. 70397414 DECAL-CP 4004I IMT 3 2 2
29. 71397349 DECAL-ANGLE INDICATOR RH, SM 3 1 1
30. 71397350 DECAL-ANGLE INDICATOR LH, SM 3 1 1
31. 70397334 DECAL-WARNING, ELEC CR OL 3 1 1
32. 70397351 DECAL-REMOTE PENDANT STORE 3 1 1
33. 70397411 DECAL-GREASE WEEKLY (LH) SMALL 3 3 3
To Next Page
