IN-COMMAND JRVCS2 User Manual

JRVCS2
6
PIN NO. WIRE GAUGE DESCRIPTION
1 18 AWG FRESH TANK 1 (IN)
2 18 AWG FRESH TANK 2 (IN)
3 18 AWG BLACK TANK 1 (IN)
4 18 AWG BLACK TANK 2 (IN)
5 18 AWG GRAY TANK 1 (IN)
6 18 AWG GRAY TANK 2 (IN)
7 18 AWG GRAY TANK 3 (IN)
8 18 AWG TANK COMMON 7V (OUT)
9 14 AWG LIGHT GROUP 1 + (IN)
10 14 AWG LIGHT GROUP 1 - (IN/OUT)
11 14 AWG LIGHT GROUP 1 + (OUT)
12 14 AWG LIGHT GROUP 2 + (IN)
13 14 AWG LIGHT GROUP 2 - (IN/OUT)
14 14 AWG LIGHT GROUP 2 + (OUT)
15 14 AWG LIGHT GROUP 3 + (IN)
16 14 AWG LIGHT GROUP 3 – (IN/OUT)
17 14 AWG LIGHT GROUP 3 + (OUT)
18 14 AWG LIGHT GROUP 4 + (IN)
19 14 AWG LIGHT GROUP 4 - (IN/OUT)
20 14 AWG LIGHT GROUP 4 + (OUT)
21 14 AWG EXTERIOR LIGHTS + (IN)
22 14 AWG EXTERIOR LIGHTS - (IN/OUT)
23 14 AWG EXTERIOR LIGHTS + (OUT)
24 14 AWG SECURITY LIGHTS + (IN)
25 14 AWG SECURITY LIGHTS - (IN/OUT)
26 14 AWG SECURITY LIGHTS + (OUT)
27 14 AWG AWNING LIGHTS + (OUT)
28 14 AWG AWNING LIGHTS - (OUT)
29 14 AWG AUX FUEL TANK + (IN)
30 14 AWG AUX FUEL TANK - (OUT)
31 AUX TRIGGER 1 (OUT)
32 18 AWG GEN START GND (OUT)
PIN NO. WIRE GAUGE DESCRIPTION
33 18 AWG GEN PRIME/STOP GND (OUT)
34 18 AWG GEN SERVICE +12V (IN)
35 18 AWG GEN HOUR METER +12V (IN)
36 14 AWG GEN FUEL TANK LEVEL (IN)
37 14/18 AWG GEN GROUND
38 16 AWG LANDING GEAR +12V (OUT)
39 16 AWG LANDING GEAR GROUND (OUT)
40 16 AWG HYDRAULIC VALVE EXTEND
41 16 AWG HYDRAULIC VALVE RETRACT
42 16 AWG HYDRAULIC VALVE +12V
43 16 AWG HYDRAULIC VALVE GROUND
44 AUX TRIGGER 2 (OUT)
45 AUX TRIGGER 3 (OUT)
46 AUX TRIGGER 4 (OUT)
47 ALARM INPUT +12V
48 ALARM INPUT +12V
49 ALARM INPUT +12V
50 ALARM INPUT +12V
51 16 AWG LOCKOUT SIGNAL +12V (IN)
52 18 AWG WATER HEATER GROUND
53 18 AWG WATER HEATER ON (GAS)
54 18 AWG WATER HEATER ON (ELECTRIC)
55 18 AWG WATER HEATER FAULT
56 14 AWG WATER PUMP +12V (OUT)
57 14 AWG WATER PUMP -12V (IN/OUT)
58 14 AWG WATER PUMP +12V (OUT)
59 14 AWG AWNING 2 -12V (OUT)
60 14 AWG AWNING 2 +12V (OUT)
61 14 AWG AWNING 1 -12V (OUT)
62 14 AWG AWNING 1 +12V (OUT)
63 10 AWG REAR JACKS -12V (OUT)
64 10 AWG REAR JACKS +12V (OUT)
PIN NO. WIRE GAUGE DESCRIPTION
65 10 AWG FRONT JACKS -12V (OUT)
66 10 AWG FRONT JACKS +12V (OUT)
67 10 AWG ELECTRIC SLIDE 5 -12V (OUT)
68 10 AWG ELECTRIC SLIDE 5 +12V (OUT)
69 10 AWG ELECTRIC SLIDE 4 -12V (OUT)
70 10 AWG ELECTRIC SLIDE 4 +12V (OUT)
71 10 AWG ELECTRIC SLIDE 3 -12V (OUT)
72 10 AWG ELECTRIC SLIDE 3 +12V (OUT)
73 10 AWG ELECTRIC SLIDE 2 -12V (OUT)
74 10 AWG ELECTRIC SLIDE 2 +12V (OUT)
75 10 AWG ELECTRIC SLIDE 1 -12V (OUT)
76 10 AWG ELECTRIC SLIDE 1 +12V (OUT)
77 10 AWG CHASSIS GROUND (IN)
78 10 AWG AWNING +12V (IN)
79 10 AWG ELECTRIC SLIDE +12V (IN)
80 10 AWG BCM +12V (IN)
81 24 AWG +12 VDC (Connect to DC)
82 24 AWG TX (Connect to DC RX)
83 24 AWG RX (Connect to DC TX)
84 24 AWG GND (Connect to DC)
• WIRING
The wiring diagram depicts all the wiring connections required for proper operation of the unit.
BODY CONTROL MODULE (BCM) CONNECTIONS
