10
NCSP35CM
• OVERRIDE SWITCHES*
The Body Control Module has override switches available.
There is a knob and switch that corresponds to motor functions 1-5
that can be made by the Display Commander and Handheld Device
App. The knob chooses the motor and the switch actuates the
motor to go in or out. There are also buttons labeled AW 1 in and
out, AW 2 in and out that act as overrides for the optional AUX Motor
Relay Control Kit. The switches and buttons are momentary and
will activate the component only while pressed in either direction.
• DISPLAY COMMANDER BUTTONS
The DC (Display Commander) has Power buttons on the front of it.
The Power Button turns the DC on and off (long press) and revives
it (short press).
Power
MicroUSB
Factory installed and RD debug used
