Once the Click-on has been secured to the bulkhead (or on the horizontal plane),
proceed with securing the compressor unit on the bracket as in Figure 5.
Figure 5: Detail of compressor unit - bracket aachment
The compressor must be installed as closely as possible to the evaporator. Evaporator
hose length is about 2 m and a sucient space for connecon and ghtening of quick
couplings must also be foreseen.
WARNING! - The unit must not be installed so that it has to be manipulated
by anyone. The housing space must only be opened voluntarily.
WARNING! - During installaon, provide a minimum distance from ammable
parts. This distance should not be less than 5 cm.
