Figure 6: Example of distances to maintain to create folds on the evaporator
5. Both the sucon hose and the small capillary hose should be rolled up carefully
before installing the evaporator, keeping the protecve covers on connecons
as long as the connecon is not going to be made. Starng from the inside of
the compartment to be cooled, lay the hose with its two connecons through
the hole made previously on the bulkhead unl reaching the compressor,
making sure not to crush or choke the hose. The excess hose must be carefully
wound in a spiral (Ø = 30 cm) before being fastened to thus prevent resulng
vibraon or noise. These acons must be completed before removing
quick coupling protecons. The hole on the unit wall must be sealed with
polyurethane foam or with insulang material.
6. Assemble the bending tool (SGH00008AA) on a work bench and fasten it with
two screws so that it remains staonary during bending operaons.
