12Paper handling
© 2015 Index Braille www.indexbraille.com
4.2 Paper loading
1. Open the lid.
2. Open the right and left tractors.
3. Release the lock on the right tractor and adjust the position of the right
tractor according to the paper width.
4. Load paper and close the tractors.
5. Stretch the paper by pulling the right tractor.
6. Lock the right tractor in chosen position.
The distance which the paper is ejected after a document is embossed should
be adjusted depending on type of acoustic protection in
Menu/system//Braille block position///feed
oFeed = 86 mm in Acoustic Hood Basic V4
oFeed = 650 mm in floor standing Acoustic Cabinet Basic (1995-2013)
oFeed = 0 in production sites where the paper should stay in embossing
head position.
1. Place the two transparent plastic paper guides on to the top of the sheet
feeder.
2. Release the lock lever on the left margin guide.
3. Open the sheet feeder by releasing the sheet feeder lock and place a paper
stack in the sheet feeder towards the right margin guide. If the paper is
slightly bended, place it with the bend against the front side of the
embosser.
4. Adjust the left margin guide to the left edge of the paper stack and lock it
with the locking lever.
5. Close the sheet feeder.
Adjust left and right card/sheet selectors for best pick-up function
a. Have both right and left card/sheet selector in bottom position, now test
by feeding a few papers.
b. If double-feed happens move both sheet/card selectors 2 step up and
try again
c. If no-feed happens move both sheet/card selector 2 step down and try
again
d. Test the sheet feeder function by a full and by a almost empty sheet
feeder
For more information see the video
"Adjusting sheet/card selector for best pick up function"
Adjust the angle of the front bottom profile by releasing the two outer white
guides and tilt the profile. Lock it in position by pressing the white outer
guides into the holes in the side plates. An almost horizontal paper eject line
when Everest is placed on a table and a 45 degrees down angle for use in
Acoustic Hood Everest V4.
Adjust the two inner document guides to line up with the paper edge.
