Infasecure CS4513 - Use; Using Inbuilt Harness

24
Ensure the restraint has been installed and set up as
per “Set Up” and “Installation” (refer Page 10 - 23)
To lengthen the harness “LIFT” the harness adjuster
(refer Figure 2) whilst grasping both shoulder harness
straps and pulling. Ensure shoulder straps are pulled
equally on each side.
Place child in car seat with legs either side of the
buckle, place harness over the shoulders and hips
(refer Figure 3) .
Step 1:
Step 2:
Step 3:
Harness
Adjuster
(Under cover)
Harness
Adjuster Strap
Top Tether
Strap
Figure 1
To ensure baby’s back is evenly supported, do not
put more than one nappy on the baby and make
sure the nappy is not thickly folded at the back.
WARNING
!
Figure 2
PULL TO
LENGTHEN
PULL TO
LENGTHEN
Harness
Adjuster
Using Inbuilt Harness
Use
Infant Seat
“LIFT” TO
LENGTHEN
Figure 3
