8
Model CS4513
CS4613
1
2
3
4
5
6
7
8
9
14
13
12
11
10
VIEW A
Seatbelt
Infant Seat
VIEW A
VIEW A
ISOFIX
Compatible
NOTE: Padded inserts can vary according to model.
For detailed description and method of attachment
for padded accessories refer to Accessories on page 50.
1. Shoulder Height Markers
2. Pillow (if fitted)
3. Comfort Cover
4. Shoulder Pads
5. Harness Straps
6. Buckle Pad
7. Padded Insert (if fitted)
8. Harness Adjuster
9. Harness Adjustment Strap
10. Vehicle Seat belt
11. Safe Grip Red Belt Clamp (supplied with restraint)
12. “REARWARD-FACING SEAT BELT PATH” Marker
(each side of restraint - coloured blue)
13. Top Tether Assembly
• Tether Strap
• Adjuster
• Attachment Clip
• Anchor Fitting + Attachment Hardware
14. ISOFIX Compatible
Lower Attachment Connectors (LAC)
