IMPORTANT
!
If so ring (02) 4728 8090 for nearest supply location. (Refer page 49)
Seat belt extenders should not be used if the seat belt is not long enough to secure the child
restraint.
Shoulder height markers may
be hidden under a pillow
Child Car Seat
Model CS4513
CS4613
1
2
3
4
5
6
7
8
9
14
13
12
11
10
Seatbelt
Forward facing
ISOFIX
Compatible
NOTE: Padded inserts can vary according to model.
For detailed description and method of attachment
for padded accessories refer to Accessories on page 50.
1. Shoulder Height Markers
2. Pillow (if fitted)
3. Comfort Cover
4. Shoulder Pads
5. Harness Straps
6. Buckle Pad
7. Padded Insert (if fitted)
8. Harness Adjuster
9. Harness Adjustment Strap
10. Vehicle Seat belt
11. Safe Grip Red Belt Clamp (supplied with restraint)
12. “FORWARD-FACING SEAT BELT PATH” Marker
(each side of restraint - coloured yellow)
13. Top Tether Assembly
• Tether Strap
• Adjuster
• Attachment Clip
• Anchor Fitting + Attachment Hardware
14. ISOFIX Compatible
Lower Attachment Connectors (LAC)
