40
Push down on the base of the restraint (with knee or
hand) whilst pulling the sash section of the vehicle
4. (This will tighten the lap belt across the seat base).
Whilst continuing to pull the sash section up, attach
the Safe Grip red belt clamp on the sash section
ONLY as close as possible above the buckle tongue
assembly. (Refer to Figure 5 and Instruction for
installing the Safe Grip red clamp below)
Ensure the excess slack in the sash belt, is fed back
towards the seat belt.
Step 3:
Step 4:
Figure 4
Installing Using Vehicle Seatbelt
Installation
Child Car Seat
Feed adult lap or lap/sash belt through the belt path
opening, ensure the seat belt is under the cover &
between the layer of foam and the plastic seat base.
(refer Figure 2 & 3).
Engage the buckle and tongue assembly (listen for a
“CLICK”). Check the buckle engagement with a
gentle pull.
Step 2:
Always use Top Tether strap to attach the
child restraint to the vehicle.
Do not use the restraint without the Top Tether
strap correctly attached and adjusted.
Do not use on any vehicle seat which faces
sideways or rearwards.
IF AN AIRBAG IS FITTED IN THE SEATING
POSITION WHERE THE CHILD RESTRAINT
IS TO BE FITTED, FOLLOW THE VEHICLE
MANUFACTURER’S WARNINGS AND
INSTRUCTIONS.
WARNING
!
Pass lap
and sash belt
through the seat.
Note: Ensure the
belts are under
foam padding.
*Note Harness
not shown
Figure 2
Figure 3
Note: Ensure the
belts are under
cover/foam padding.
Buckle &
Tongue
Assembly
“CLICK”
Lap and
sash belts
pass across
the base
REMOVE ALL
SLACK FROM
SEATBELT
To Next Page
