Accessories
SHOULDER PADS (if tted)
The shoulder pad is designed to add extra
comfort for baby or child.
STANDARD
Separate press-studs and remove the
shoulder pads from harness
To attach shoulder pads, ensure press studs
face away from the child and re-attach.
Step 1:
Step 2:
SPREADER
PLATE
DELUXE
Loosen harness to allow spreader plate to
rise from under the restraint. Turn the
restraint so that the back of the seat is
facing you.
Remove each shoulder harness through
the gates in the spreader plate (refer Figure
1 & 2).
Pull the shoulder harness straps through the
shoulder slot holes in the seat body and
cover. They are now loose in the front of the
seat (refer Figure 2).
To attach shoulder pads, slide the shoulder
pad over the harness straps (refer Figure 3).
Rethread harness straps (in applicable slots)
as per Steps 1 to 3 above.
Step 1:
Step 2:
Step 3:
Step 4:
Step 5:
Figure 1
Figure 3
STANDARD
DELUXE
HARNESS
STRAPS
METAL
SPREADER
PLATE
PULL
Figure 2
