Inficon BPG400 User Manual

10 tina03e1 (0206) BPG400 v1.om
Data rate
Data format
Connections (sensor cable connector)
TxD (Transmit Data)
RxD (Receive Data)
GND
9600 baud
binary
8 data bits
one stop bit
no parity bit
no handshake
Pin 13
Pin 14
Pin 5
(Function and communication protocol of the RS232C interface ® 2 32)
Fieldbus name DeviceNet
Standard applied
® & [6]
Communication protocol, data format
® & [1], [4]
Interface, physical CAN bus
Data rate (adjustable via "RATE"
switch)
125 kbaud
250 kbaud
500 kbaud
"P" (125 kbaud, 250 kbaud, 500 kbaud
programmable via DeviceNet
(® & [1])
Node address (MAC ID)
(Adjustable via "ADDRESS", "MSD",
"LSD" switches)
0 … 63
dec
"P" (0 … 63 programmable via
DeviceNet, ® & [1])
DeviceNet connector Micro-Style, 5 pins, male
Cable Shielded, special DeviceNet cable,
5 conductors (® 2 24 and & [4])
Cable length, system wiring According to DeviceNet specifications
(® & [6], [4])
Fieldbus name Profibus
Standard applied
® & [7]
Communication protocol data format
® & [10], [7]
Interface, physical RS485
Data rate
£12 Mbaud (® & [10])
Node address
(Adjustable via hexadecimal
"ADDRESS", "MSD", "LSD" switches)
00 … 3F
hex
(0 … 127
dec
)
Profibus connection D-Sub, 9 pins, female
Cable Shielded, special Profibus cable
(® 2 25 and & [5])
Cable length, system wiring According to Profibus specifications
(® & [7], [5])
RS232C interface
DeviceNet interface
(BPG400-SD)
Profibus interface
(BPG400-SP)
